F520 DWDM Mux-Demux
DWDM Mux / Demux Module
Features:
- 100GHz Channel Spacing
- Support up to 16 channels
- Plug and play, no configuration required
- Passive products without power and cooling needs
- High Isolation and Low Insertion Loss
- High integration card package
- Stable and Reliable performance
- Support Monitoring and Express channel
| Inquiry | Parameters | Specification Values | Download |
|---|---|---|---|
Fiber Type Center Wavelength Channel Spacing Center Wavelength Accuracy Maximum Handling Power Size Operating Temperature Storage Temperature Relative Humidity (no condensation) | SMF-28e or equivalent Single Mode Fiber ITU-Grid nm 100GHz ±0.05nm 300mW 191(W) x 253(D) x 20(H)mm -10 ~ +60°C -40 ~ +85°C 5 ~ 95RH% |  |
